China Supplier Aluminum Round Tubing 6063 6181 6082 6005 Aluminum 2
Inch Pipe Tube
6005 aluminum pipe tube is a medium-strength aluminum alloy mainly
used for some structural profiles.
6005 aluminum pipe tube has excellent extrusion performance and can
be quenched on the extrusion machine train.
6005 aluminum pipe has medium strength, good plasticity, corrosion
resistance, weldability and processability, and excellent overall
performance. The tensile strength and yield strength of the 6005
aluminum pipe tube are equal to that of 6063, the elongation is
twice that of 6063, and the mechanical properties are higher than
that of the 6063 aluminum pipe tube.
1, Product Parameters :
1)Product Specification and Steel Grade
| Type | 6005Aluminum Pipe Tube |
|
| 1000 Series | 1050 1060 1070 1100 |
| 2000 Series | 2024(2A12), LY12, LY11, 2A11, 2A14(LD10), 2017, 2A17 |
| 3000 Series | 3A21, 3003, 3103, 3004, 3005, 3105 |
| 4000 Series | 4A03, 4A11, 4A13, 4A17, 4004, 4032, 4043, 4043A, 4047, 4047A |
| 5000 Series | 5052, 5083, 5754, 5005, 5086,5182 |
| 6000 Series | 6063, 6061, 6060, 6351, 6070, 6181, 6082, 6A02,6005 |
| 7000 Series | 7075,7050,7A04,7472,7475 |
| Specification for round pipe | OD: 15mm-160mm; WT: 0.3-50mm; Length: 1-12m |
| Specification for square pipe | SIZE:7X7mm- 150X150 mm; WT: 1-40mm; Length:1-12m |
| Surface | Mill finished, anodized, powder coating, Sandblas, etc |
| Temper | H111 H112 H116/H321 H12/H22/H32 H14/H24/H34/H16/H26/H36 H18/H28/H38
H11. |
| MOQ | 5ton, We can accept sample orders. |
| Delivery port | Shanghai, Tianjin, Qingdao, Ningbo, Guangzhou, etc. |
| Packaging Detail | Standard export packaging, various transportation, according to
customer needs |
2)Chemical Composition
| Alloy | Si | Fe | Cu | Mn | Mg | Cr | Zn | Ti | Others: | Others: | Al: Min. |
| Each | Total |
| 1050 | 0.25 | 0.4 | 0.05 | 0.05 | 0.05 | - | 0.05 | 0.03 | 0.03 | - | 99.5 |
| 1060 | 0.25 | 0.35 | 0.05 | 0.03 | 0.03 | - | 0.05 | 0.03 | 0.03 | - | 99.6 |
| 1100 | 0.95 Si + Fe | 0.05~0.20 | 0.05 | - | - | 0.1 | - | 0.05 | 0.15 | 99 |
| 3003 | 0.6 | 0.7 | 0.05~0.20 | 1.0~1.5 | - | - | 0.1 | - | 0.05 | 0.15 | remainder |
| 2A12 | 0.50 | 0.50 | 3.8-4.9 | 0.3-0.9 | 1.2-1.8 | - | 0.30 | 0.15 | 0.05 | 0.15 | remainder |
| 2017 | 0.2-0.8 | 0.7 | 3.5-4.5 | 0.4-1.0 | 0.4-0.8 | 0.10 | 0.25 | 0.15 | 0.05 | 0.15 | remainder |
| 3A21 | 0.6 | 0.7 | 0.20 | 1.0-1.6 | 0.05 | - | 0.10 | 0.15 | 0.05 | 0.05 | remainder |
| 3004 | 0.3 | 0.7 | 0.25 | 1.0~1.5 | 0.8~1.3 | - | 0.25 | - | 0.05 | 0.15 | remainder |
| 3005 | 0.6 | 0.7 | 0.3 | 1.0~1.5 | 0.2~0.6 | 0.1 | 0.25 | 0.1 | 0.05 | 0.05 | remainder |
| 5A06 | 0.4 | 0.4 | 0.4 | 0.5-0.8 | 5.8-6.8 | - | 0.20 | 0.02-0.10 | 0.05 | 0.1 | remainder |
| 5A02 | 0.4 | 0.4 | 0.4 | 0.15-0.4 | 20.-2.8 | - | - | 0.15 | 0.05 | 0.05 | remainder |
| 5005 | 0.3 | 0.7 | 0.2 | 0.2 | 0.5~1.1 | 0.1 | 0.25 | - | 0.05 | 0.15 | remainder |
| 5052 | 0.25 | 0.4 | 0.1 | 0.1 | 2.2~2.8 | 0.15~0.35 | 0.1 | - | 0.05 | 0.15 | remainder |
| 5754 | 0.4 | 0.4 | 0.1 | 0.5 | 2.6~3.6 | 0.3 | 0.2 | 0.15 | 0.05 | 0.15 | remainder |
| 5083 | 0.4 | 0.4 | 0.1 | 0.4~1.0 | 4.0~4.9 | 0.05~0.25 | 0.25 | 0.15 | 0.05 | 0.05 | remainder |
| 6005 | 0.17-0.35 | 1.6-2.5 | 0.1-0.25 | 0.15-0.3 | 0.05-0.1 | 0.1 | 1-1.4 | 0.15 | 0.05 | 0.05 | remainder |
| 7A04 | 0.5 | 0.5 | 1.4-2.0 | 0.2-0.6 | 1.8-2.8 | 0.1-0.25 | 2.0-7.0 | 0.1 | 0.05 | 0.05 | remainder |
Aluminum Pipe Workshop:
Aluminum Pipe Application:
6005 aluminum tubes have guaranteed mechanical properties when used
on building curtain walls. After testing by the Quality Center,
their air permeability, rainwater permeability, wind pressure
deformation performance, and in-plane deformation performance have
all reached the first-level level stipulated in national standards.
6005 aluminum tube is mainly used to manufacture welded structural
parts, and mechanical parts with high plasticity and high corrosion
resistance.
6005 aluminum tubes are mainly used in the manufacture of urban
rail passenger cars, railway passenger cars, especially high-speed
EMUs.
Aluminum Pipe Package:
FAQ
Q1. Where is your factory?
A1: Our company’s processing center is located in Foshan, Guangdong, China. It is well equipped with kinds of machines, such as laser
cutting machine, mirror polishing machine and so on. We can provide
a wide range of personalized services according to the customers’
needs.
Q2. What are your company's main products?
A2: Our main products are stainless steel plate/sheet, coil,
round/square pipe, bar, channel, etc.
Q3. How do you control quality?
A3: Mill Test Certification is supplied with shipment, Third Party
Inspection is available.
Q4. What are the advantages of your company?
A4: We have many professionals, technical personnel, more
competitive prices, and better after-sale service than other
stainless steel companies.
Q5. How many countries have you already exported?
A5: Exported to more than 50 countries mainly from America, Russia,
UK, Kuwait, Egypt, Turkey, Jordan, India, etc.
Q6. Can you provide a sample?
A6: Small samples in store and can provide the samples for free.
Customized samples will take about 5-7 days.
