5x10 Aluminum Sheet 2mm 3mm 4mm Thickness 2024(2A12), LY12, LY11,
2A13 ,2017 Aluminum Plate Metal
2017 aluminum alloy sheet is a high-strength heat-treatable alloy
in the 2xxx series.
The characteristics of the 2017 aluminum alloy sheet are: high
strength, certain heat resistance, and can be used as working parts
below 150°C. At temperatures above 125°C, the strength of the 2017
aluminum alloy sheet is higher than that of the 7075 alloy. The
forming properties of the 2017 aluminum alloy sheet are relatively
good in the hot state, annealed, and newly quenched state, and the
heat treatment strengthening effect is remarkable, but the heat
treatment process requirements are strict.
Product Parameters :
1)Product Specification and Steel Grade
| Type | 2017 Aluminum Sheet |
|
| 1000 Series | 1050 1060 1070 1100 |
| 2000 Series | 2024(2A12), LY12, LY11, 2A13, 2A14(LD10), 2017, 2A17 |
| 3000 Series | 3A21, 3003, 3103, 3004, 3005, 3105 |
| 4000 Series | 4A03, 4A11, 4A13, 4A17, 4004, 4032, 4043, 4043A, 4047, 4047A |
| 5000 Series | 5052, 5083, 5754, 5005, 5086,5182 |
| 6000 Series | 6063, 6061, 6060, 6351, 6070, 6181, 6082, 6A02 |
| 7000 Series | 7075,7050,7A04,7472,7475 |
| Thickness(mm) | aluminum plate 0.2mm-300mm |
| Width(mm) | 100-2800mm |
| Length(mm) | 2000mm,2440mm,6000mm, or as required. |
| Surface | Wire drawing, oxidation, PS, Mirror surface, Embossing etc |
| Temper | H111 H112 H116/H321 H12/H22/H32 H14/H24/H34/H16/H26/H36 H18/H28/H38
H114 |
| Type | coil/sheet/strips/plate |
| Payment | L/C, T/T, D/P, West Union, etc. |
| Package | Standard export packages, such as Wooden pallets |
2)Chemical Composition
| Alloy | Si | Fe | Cu | Mn | Mg | Cr | Zn | Ti | Others: | Others: | Al: Min. |
| Each | Total |
| 1050 | 0.25 | 0.4 | 0.05 | 0.05 | 0.05 | - | 0.05 | 0.03 | 0.03 | - | 99.5 |
| 1060 | 0.25 | 0.35 | 0.05 | 0.03 | 0.03 | - | 0.05 | 0.03 | 0.03 | - | 99.6 |
| 1100 | 0.95 Si + Fe | 0.05~0.20 | 0.05 | - | - | 0.1 | - | 0.05 | 0.15 | 99 |
| 3003 | 0.6 | 0.7 | 0.05~0.20 | 1.0~1.5 | - | - | 0.1 | - | 0.05 | 0.15 | remainder |
| 3004 | 0.3 | 0.7 | 0.25 | 1.0~1.5 | 0.8~1.3 | - | 0.25 | - | 0.05 | 0.15 | remainder |
| 3005 | 0.6 | 0.7 | 0.3 | 1.0~1.5 | 0.2~0.6 | 0.1 | 0.25 | 0.1 | 0.05 | 0.15 | remainder |
| 5005 | 0.3 | 0.7 | 0.2 | 0.2 | 0.5~1.1 | 0.1 | 0.25 | - | 0.05 | 0.15 | remainder |
| 5052 | 0.25 | 0.4 | 0.1 | 0.1 | 2.2~2.8 | 0.15~0.35 | 0.1 | - | 0.05 | 0.15 | remainder |
| 5754 | 0.4 | 0.4 | 0.1 | 0.5 | 2.6~3.6 | 0.3 | 0.2 | 0.15 | 0.05 | 0.15 | remainder |
| 5083 | 0.4 | 0.4 | 0.1 | 0.4~1.0 | 4.0~4.9 | 0.05~0.25 | 0.25 | 0.15 | 0.05 | 0.15 | remaind |
AluminumSheet Product Factory Building:
2017 aluminum alloy sheet Chemical Composition:
Copper (Cu): 3.5-4.5%; Manganese (Mn): 0.4-1.0%; Magnesium (Mg):
1.2-2.0%; Iron (Fe): 0.7%; Silicon (Si): 0.2-0.8%; Zinc (Zn):
0.7-1.3%; Titanium (Ti): 0.15%; Others (each): 0.05%; Others
(total): 0.15%; Aluminum (Al): Remaining balance.
Aluminum Sheet Application:
2017 aluminum alloy sheet Widely used in aircraft structures,
rivets, truck hubs, propeller components, and various other
structural parts.
2017 aluminum plate is usually used in rivets, general mechanical
parts, aircraft, ships, transportation, building structural parts,
transportation structural parts, propeller components and
accessories, etc.
2017 aluminum alloy sheet used in certain parts of the
transportation industry, such as automotive components.
Machined Parts: A 2017 aluminum alloy sheet is often chosen for
applications where excellent machinability is a priority.
Aluminum Sheet Package:
Standard Seaworthy Wood Pallets, or according to customer's
requests.
