Aluminum Round Industrial Tube 3A21, 3003, 3103, 3004 Anodized
Aluminum Alloy Pipe Price
3A21-H112 aluminum pipe is an Al-Mn alloy, which is the most widely
used anti-rust aluminum. The strength of the 3A21-H112 aluminum
pipe is not high and cannot be strengthened by heat treatment. Cold
working methods are often used to improve its mechanical
properties. 3A21-H112 aluminum tube has high plasticity in the
annealed state, good plasticity during semi-cold work hardening,
low plasticity during cold work hardening, good corrosion
resistance, good weldability, and poor machinability.
1, Product Parameters :
1)Product Specification and Steel Grade
| Type | 3A21 Aluminum Pipe Tube |
|
| 1000 Series | 1050 1060 1070 1100 |
| 2000 Series | 2024(2A12), LY12, LY11, 2A11, 2A14(LD10), 2017, 2A17 |
| 3000 Series | 3A21, 3003, 3103, 3004, 3005, 3105 |
| 4000 Series | 4A03, 4A11, 4A13, 4A17, 4004, 4032, 4043, 4043A, 4047, 4047A |
| 5000 Series | 5052, 5083, 5754, 5005, 5086,5182 |
| 6000 Series | 6063, 6061, 6060, 6351, 6070, 6181, 6082, 6A02 |
| 7000 Series | 7075,7050,7A04,7472,7475 |
| Specifcation for round pipe | OD: 15mm-160mm; WT: 0.3-50mm; Length: 1-12m |
| Specification for square pipe | SIZE:7X7mm- 150X150 mm; WT: 1-40mm; Length:1-12m |
| Surface | Mill finished, anodized, powder coating, Sandblas, etc |
| Temper | H111 H112 H116/H321 H12/H22/H32 H14/H24/H34/H16/H26/H36 H18/H28/H38
H11. |
| MOQ | 5ton, We can accept sample orders. |
| Delivery port | Shanghai, Tianjin, Qingdao, Ningbo, Guangzhou, etc. |
| Packaging Detail | Standard export packaging, various transportation, according to
customer needs |
2)Chemical Composition
| Alloy | Si | Fe | Cu | Mn | Mg | Cr | Zn | Ti | Others: | Others: | Al: Min. |
| Each | Total |
| 1050 | 0.25 | 0.4 | 0.05 | 0.05 | 0.05 | - | 0.05 | 0.03 | 0.03 | - | 99.5 |
| 1060 | 0.25 | 0.35 | 0.05 | 0.03 | 0.03 | - | 0.05 | 0.03 | 0.03 | - | 99.6 |
| 1100 | 0.95 Si + Fe | 0.05~0.20 | 0.05 | - | - | 0.1 | - | 0.05 | 0.15 | 99 |
| 3003 | 0.6 | 0.7 | 0.05~0.20 | 1.0~1.5 | - | - | 0.1 | - | 0.05 | 0.15 | remainder |
| 2A12 | 0.50 | 0.50 | 3.8-4.9 | 0.3-0.9 | 1.2-1.8 | - | 0.30 | 0.15 | 0.05 | 0.15 | remainder |
| 2017 | 0.2-0.8 | 0.7 | 3.5-4.5 | 0.4-1.0 | 0.4-0.8 | 0.10 | 0.25 | 0.15 | 0.05 | 0.15 | remainder |
| 3A21 | 0.6 | 0.7 | 0.20 | 1.0-1.6 | 0.05 | - | 0.10 | 0.15 | 0.05 | 0.05 | remainder |
| 3004 | 0.3 | 0.7 | 0.25 | 1.0~1.5 | 0.8~1.3 | - | 0.25 | - | 0.05 | 0.15 | remainder |
| 3005 | 0.6 | 0.7 | 0.3 | 1.0~1.5 | 0.2~0.6 | 0.1 | 0.25 | 0.1 | 0.05 | 0.05 | remainder |
| 5A06 | 0.4 | 0.4 | 0.4 | 0.5-0.8 | 5.8-6.8 | - | 0.20 | 0.02-0.10 | 0.05 | 0.1 | remainder |
| 5A02 | 0.4 | 0.4 | 0.4 | 0.15-0.4 | 20.-2.8 | - | - | 0.15 | 0.05 | 0.05 | remainder |
| 5005 | 0.3 | 0.7 | 0.2 | 0.2 | 0.5~1.1 | 0.1 | 0.25 | - | 0.05 | 0.15 | remainder |
| 5052 | 0.25 | 0.4 | 0.1 | 0.1 | 2.2~2.8 | 0.15~0.35 | 0.1 | - | 0.05 | 0.15 | remainder |
| 5754 | 0.4 | 0.4 | 0.1 | 0.5 | 2.6~3.6 | 0.3 | 0.2 | 0.15 | 0.05 | 0.15 | remainder |
| 5083 | 0.4 | 0.4 | 0.1 | 0.4~1.0 | 4.0~4.9 | 0.05~0.25 | 0.25 | 0.15 | 0.05 | 0.15 | remainder |
Aluminum Coil Workshop:
Aluminum Pipe Application:
3A21-H112 aluminum tube has high plasticity and good weldability,
and can be used in low-load parts working in liquid or gas media,
such as fuel tanks, gasoline or lubricating oil conduits.
3A21 aluminum tubes can be used as tanks and tanks for kitchen
utensils, food and chemical product processing.
3A21 aluminum tubes can be used to make heat sinks, cosmetic
boards, photocopier rollers, etc.
Aluminum Coil Package:
FAQ
Q1. Where is your factory?
A1: Our company’s processing center is located in Foshan, Guangdong, China. It is well equipped with kinds of machines, such as laser
cutting machine, mirror polishing machine and so on. We can provide
a wide range of personalized services according to the customers’
needs.
Q2. What are your company's main products?
A2: Our main products are stainless steel plate/sheet, coil,
round/square pipe, bar, channel, etc.
Q3. How do you control quality?
A3: Mill Test Certification is supplied with shipment, Third Party
Inspection is available.
Q4. What are the advantages of your company?
A4: We have many professionals, technical personnel, more
competitive prices, and better after-sale service than other
stainless steel companies.
Q5. How many countries have you already exported?
A5: Exported to more than 50 countries mainly from America, Russia,
UK, Kuwait, Egypt, Turkey, Jordan, India, etc.
Q6. Can you provide a sample?
A6: Small samples in store and can provide the samples for free.
Customized samples will take about 5-7 days.
